Polyester Acrylate 5312 is a high-performance UV resin featuring excellent compatibility with most UV monomers and resins. It is widely used in large-area spraying, printing varnishes, and inks, offering key advantages such as fast curing speed, excellent leveling, good ink wettability, high gloss, and strong adhesion—making it an ideal choice for advanced coating and printing applications.
Firstly, 5312 provides a fast curing speed, enabling rapid film formation under UV light. This greatly shortens production cycles and improves efficiency, making it particularly suitable for large-area spraying and high-speed printing processes.
Secondly, it demonstrates excellent leveling performance, allowing the coating to spread evenly and minimize defects such as streaks or brush marks. At the same time, its good ink wettability enhances pigment and substrate compatibility, resulting in improved print quality and sharper visual effects.
In terms of appearance, 5312 delivers high gloss, creating a bright, full-bodied surface finish that enhances the overall visual appeal of the end product. Additionally, its strong adhesion ensures reliable bonding to a wide range of substrates, preventing issues like peeling or delamination and ensuring long-lasting coating stability.
With this well-rounded performance, Polyester Acrylate 5312 not only supports efficient production but also delivers superior aesthetics and durability. Choose 5312 to elevate your UV systems with efficiency, quality, and reliability, achieving outstanding results in both coatings and printing.
| Parameter | Specification |
|---|---|
| Resin type | 5312 Polyester Acrylate Resin |
| Appearance | Transparent viscous liquid |
| Viscosity（mPa.s） | 400~1500 (25ºC) |
| Functionality | 3 |
| Chrominance（Pt-Co) | ≤50 |
| Acid value(mgKOH/g) | ≤5 |
| Packaging | 20/200 (kg) / Closed ordinary steel drum |
| Warranty Period | 90 days |
This product should be stored and transported in dark opaque steel drums or containers containing corrosion-resistant and solvent-resistant coatings. Leave at least 15% space inside the container filled with air. Packaging should be stored in a cool environment below 35 ℃, and exposure to sunlight is strictly prohibited.
Polyester Acrylate 5312 is a high-performance UV resin with functionality of 3, designed for large-area spraying, printing varnishes, and high-speed inks. It features excellent compatibility with most UV monomers and resins.
It delivers fast curing speed for shorter production cycles, excellent leveling to minimize defects, good ink wettability for better pigment compatibility, high gloss, and strong adhesion on various substrates.
It is a transparent viscous liquid with a viscosity of 400~1500 mPa.s at 25ºC, functionality of 3, chrominance (Pt-Co) of ≤50, and an acid value of ≤5 mgKOH/g.
It must be stored in dark, opaque steel drums or containers with corrosion and solvent-resistant coatings. The storage environment should be kept below 35 ℃, away from direct sunlight, leaving at least 15% air space inside the container.
The product has a warranty period of 90 days. It is packed and supplied in closed ordinary steel drums containing either 20 kg or 200 kg of resin.
