1735 is a cutting-edge pure acrylate UV resin designed to address two common challenges in the photocuring industry: volume shrinkage and insufficient adhesion. During UV curing, volume shrinkage often leads to increased internal stress, causing substrate warpage or coating delamination, but 1735 achieves an exceptionally low shrinkage rate through its unique molecular structure design, making it particularly suitable for coating precision plastic parts requiring high dimensional stability and for treating thin wood veneers prone to deformation, ensuring a perfectly flat finish. Unlike traditional brittle resins, 1735 forms a highly ductile cross-linked network upon curing; this outstanding flexibility endows the coating with excellent impact resistance and bendability, making it an ideal choice for folding packaging inks and coatings for flexible plastic parts such as mobile phone cases and automotive interiors. Furthermore, 1735 demonstrates strong wetting and bonding capabilities on both polar and non-polar substrates, significantly improving coating adhesion on difficult-to-bond plastics like ABS, PC, and PVC as well as wood and metal surfaces. In formulations, it can serve as a primary resin providing base properties or be added as an adhesion promoter to drastically boost the bonding strength of the entire system at a low cost. It is widely used in UV wood coatings, UV plastic coatings, and UV screen/offset printing inks, making 1735 an indispensable formulation component for high-end applications demanding high durability and a defect-free appearance.
| Resin type | pure acrylate oligomer 1735 |
| Appearance | Transparent viscous liquid |
| Viscosity(mPa.s) | 40000~70000 (25ºC) |
| Functionality | 2 |
| Chrominance(Pt-Co) | ≤100 |
| Acid value(mgKOH/g) | / |
Acts as a cost-effective additive to significantly boost overall system bonding performance.
Perfect for precision plastic electronics, automotive interiors, and warp-sensitive wood veneers.
Ideal for high-flexibility applications such as folding packaging and offset screen inks.
| Packaging | 20/220 (kg)/Opened ordinary steel drum |
| Warranty period | 180 days |
| Storage | This product should be stored and transported in dark opaque steel drums or containers containing corrosion-resistant and solvent resistant coatings. Leave at least 15% space inside the container filled with air. Packaging should be stored in a cool environment below 35 ℃, and exposure to sunlight is strictly prohibited. |
1735 features an exceptionally low volume shrinkage design. This minimizes internal stress during photocuring, preventing substrate warping or coating delamination on precision components.
It demonstrates superior wetting and adhesion on both polar and non-polar substrates, including challenging plastics like ABS, PC, and PVC, as well as wood and metals.
Yes. It can function either as a primary resin providing base properties or be added at a low ratio as an adhesion promoter to cost-effectively upgrade the bond strength of the entire formulation.
It is a transparent viscous liquid with a functionality of 2 and a viscosity range of 40,000 to 70,000 mPa.s at 25ºC.
It must be stored in dark, opaque, corrosion-resistant steel containers with at least 15% air headspace. Keep the storage temperature below 35 ℃ and avoid any direct exposure to sunlight.
